Explore Hellebusch Tool & Die machining and manufacturing equipment, including 5-axis CNC, large-format horizontal machining, high-speed vertical CNC, EDM, inspection and tooling support. Machine specifications are provided to help evaluate project fit.
| Machine | Spindle / power | Table / rated capacity | X × Y × Z travel |
|---|---|---|---|
| FIDIA DL321 | 15,000 RPM • 74 HP | 118 × 79 in • 1,434 lb/ft² | 118 × 86.6 × 49 in |
| FIDIA K199 | 24,000 RPM • 46 HP | 79 × 49 in • 15,430 lb | 70 × 35.5 × 33 in |
| DMG DMU125P | 10,000 RPM • 35 HP | 39 in round • 2,200 lb | 49 × 35 × 31 in |
| Hermle C650 | 16,000 RPM • 56 HP | 35 × 29 in • 6,600 lb | 41 × 35 × 23 in |
| Machine | Spindle | Pallet / workpiece capacity | X × Y × Z travel |
|---|---|---|---|
| OKK HM-1600 | 5,500 RPM • 50 HP | 98.4 x 72.8 in • 25,000 lb | 94.5 × 65 × 68.9 in |
| Giddings & Lewis PC-50 | 4,000 RPM • 50 HP | 60 x 144 in • 25,000 lb | 98.42 × 82.67 × 62 in |
| OKK HM-1250S | 8,000 RPM • 50/40 HP | 49.21 × 49.21 in • 11,000 lb | 66.93 × 55.12 × 48.82 in |
| OKK HM-100S | 12,000 RPM • 40/33.5 HP | 39.4 × 39.4 in • 5,510 lb | 55.12 × 43.31 × 39.37 in |
| Makino A77 | 10,000 RPM | Dual 25 × 25 in • 2,645 lb | 31.5 × 29.5 × 30.3 in |
| Machine / qty | Spindle | Table / rated load | X × Y × Z travel |
|---|---|---|---|
| Makino V56 | 20,000 RPM • 25 HP | 41.3 × 21.6 in • 1,763 lb | 35.4 × 21.6 × 17.7 in |
| OKK VM5-II | 20,000 RPM • 25 HP | 41.34 × 22.05 in • 1,760 lb | 40 × 20 × 20 in |
| OKK VB53 | 20,000 RPM | 49.61 × 23.62 in • 2,646 lb | 40 × 20 x 20 in |
| Makino SNC64 | 20,000 RPM • 7.5 HP | 29.5 × 15.7 in • 550 lb | 23 × 15.75 × 15.75 in |
| Makino SNC106 | 15,000 RPM • 5 HP | 43.3 × 23.6 in • 2,205 lb | 39.4 × 23.6 × 15.75 in |
| Makino S56 | 20,000 RPM • 20 HP | 39.4 × 19.7 in • 1,102 lb | 35.4 × 19.7 × 17.7 in |
| YCM NSV102A (2) | 12k / 15k RPM • 30 HP | 25.5 × 44 in • 2,200 lb | 40 × 23.6 × 23.6 in |
| YCM WV108A | 15,000 RPM • 30 HP | 51.18 × 32.28 in • 2,645 lb | 44 × 30 x 27.5 in |
| YCM WV108B | 10,000 RPM • 30 HP | 51.18 × 32.28 in • 2,645 lb | 44 × 30 × 30 in |
| YCM NTV-158B (2) | 15,000 RPM • 40 HP | 64.96 × 29.92 in• 4,400 lb | 60.24 × 30 × 27.56 in |
| Hurco VMX50 | 10,000 RPM • 24 HP | 26 × 59 in • 3,000 lb | 50 × 26 × 24 in |
| Hurco 4020 | 8,000 RPM | 48 × 20 in • 1,500 lb | 40 × 20 × 24 in |
| Hurco VMX42S (2) | 10,000 RPM • 24 HP | 50 × 24 in • 3,000 lb | 42 × 24 × 24 in |
| Equipment | Process | Travel / working envelope | Maximum workpiece |
|---|---|---|---|
| Mitsubishi MV4800 | Wire EDM | 31.5 × 23.6 × 20.1 in travel | 53.1 × 43.3 × 20 in • 6,600 lb |
| Mitsubishi FX20K | Wire EDM | 19.6 × 13.7 in travel | 41.3 × 31.4 × 11.6 in • 1,760 lb |
| Charmilles Roboform 40 (2) | Sinker EDM | 19.7 × 15.7 in • 48 × 32 in tank | 39.37 × 27.55 × 14.56 in • 2,200 lb |
| AgieCharmilles FORM 400 (2) | Sinker EDM • 140 A | 35.43 × 27.56 × 19.68 in travel | 71.42 x 47.83 • 6,613 lb |
| Equipment | Key capability |
|---|---|
| Okuma Captain I370-M CNC lathe | Live tooling • 3,800 RPM • 30 HP • 13.38 in turning diameter • 19.68 in length |
| Zeiss Eclipse CMM | 40 × 64 × 24 in measuring envelope • 3,500 lb • Renishaw PH10T |
| Walter Reis 100-ton spotting press | 61 × 87 in platen |
| Walter Reis 40-ton spotting press | 35 × 47 in platens • swiveling top / sliding and pivoting bottom |
| 3-ton hydraulic spotting press | 17 × 29 in through tie bars |
| Equipment | Capacity / features |
|---|---|
| Electric heat-treat furnace | 12 × 12 × 18 in • controlled nitrogen atmosphere |
| Stress-relieving furnace | 30 × 30 × 48 in • 2,000 lb • 1,000°F maximum |
| Bridge cranes | 1 × 40-ton • 2 × 20-ton • 2 × 10-ton • 1 × 6-ton • 2 × 2-ton |
| Hyster S150 forklift | 15,300 lb capacity |
| Capability | Equipment / software |
|---|---|
| CAD/CAM and engineering | Kubotek • SolidWorks • Unigraphics • Mastercam • WorkNC • PowerMill • Flow-3D |
| Plastic injection sampling | Injection molding machines in the 100–610 ton range |
| Extrusion sampling | Davis-Standard plastic extruder • Model 2.5 PMIV |
